Quick Details

  • Place of Origin: Jiangsu, China (Mainland)
  • Brand Name: THE -Solar
  • Model Number: 4Z 8-20-0.75
  • Structure: Single-stage Pump
  • Usage: Irrigation
  • Power: 900w
  • Standard or Nonstandard: Standard
  • Fuel: solar power
  • Pressure: High Pressure
  • Application: home use
  • Work Voltage: 220V
  • Rated Flow: 8 Ton/hour
  • Max Flow: 12 Ton/hour
  • Rated Head: 20m
  • Max Head: 25m
  • Outlet: 32mm
  • Motor: Permanent magnet synchronous motor
  • Bearing: Japan NSK Bearing
  • Material: Stainless Steel
  • Certificate: CE Certificate

Packaging & Delivery

Packaging Details pump unit in one carton, controller in one carton
Delivery Time 15-20 days after receive the payment

                                                       Price of Submersible  Solar Water Pump



Product characteristic



  • High Efficiency and high-speed Stepless Speed Regulation Motor
  • Small Voltage(1/4) and Light Weight(1/3)
  • Automatic Working Model
  • Pressure and Flow Control Model
  • Timer Switch
  • Downwhole Waterless Automatic Control
  • Multifunctional Automatic Protection
  • Used Both at 50HZ and 60HZ
  • Wide Voltage Constant Output
  • Network Single control or Multi-Devices Control
  • AC,DC and Solar Power Input





TYPE

FLOW

Rated/Max

(Ton/hour)

HEAD

Rated/Max

(Meter)

PUMP

POWER

(KW)

SOLAR

POWER

(KW)

PUMP

VOLTAGE

(Vol)

MOTOR

SPEED

(r/min)

PUMP

HEIGHT

(mm)

PUMP

WEIGHT

(Kg)

PUMP

OUTLET

(mm)

PUMP

DIAMETER

(mm)

PACKING

SIZE

(mm)

4Z 8-20-0.75

8/12

20/25

0.9

1.35

220V

4200

500

8

38

5-2

150*150*550

4Z 8-26-1.1

8/13

26/36

1.38

2.07

220V

5000

500

8

38

5-2

150*150*550

4Z 2-70-1.1

2/7

70/85

1.4

2.1

220V

7200

530

8.1

38

1.8-3

150*150*650

4Z 3-50-1.1

3/8

50/65

1.4

2.1

220V

7200

500

8

38

1.8-2

150*150*550

4Z 4-40-1.1

4/6.6

40/48

1.3

1.95

220V

5700

530

8.2

38

3-2

150*150*650

4Z 10-18-1.1

10/20

18/22

1.29

1.93

220V

4000

510

8.2

38

10-2

150*150*550

4Z 2-100-1.5

2/7

100/115

1.85

2.78

220V

7200

540

8.3

38

1.8-4

150*150*650

4Z 5-50-1.5

5/10

50/85

1.85

2.78

220V

7200

495

8

38

2-2

150*150*550

4Z 6-45-1.5

6/12

45/65

1.85

2.78

220V

7200

500

8.2

38

3-2

150*150*550

4Z 10-30-1.5

10/14

30/44

1.8

2.7

220V

5500

500

8

38

5-2

150*150*550

4Z 13-22-1.5

13/23

22/28

1.85

2.78

220V

4500

510

8.2

50

10-2

150*150*550

4Z 10-37-1.8

10/14

37/52

2.35

3.53

220V

6000

500

8

38

5-2

150*150*550

4Z 10-45-2.2

10/14

45/60

2.85

4.27

220/380V

6500

500

8

38

5-2

150*150*550













DC solar water pump system appliction:

  • Pasture irrigation
  • Desertification control
  • Fountain
  • Domestic water
  • Agriculture irrigation
  • Desalination of sea water
  • Drinking water
  • Dripping irrigation.
